Detailed Description

template<class GlobalAttr, class StateAttr, class EventAttr, class TransAttr>
class faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >

Allows to create colored marking generators (CMGs) as the common five tupel consisting of alphabet, stateset, transition relation, initial states, marked states, and attributes for state and event properties.

Thus, it is possible to set a control status for events and to add or delete colored markings to single states. Doing so, multitasking generators can be computed and their behaviour be analysed.Methods for examining the color status are included as well as those for making a CMG accessible or strongly coaccessible. Furthermore, input and output methods for MtcSystems are included.

Definition at line 53 of file mtc_generator.h.

#include <mtc_generator.h>

Public Member Functions
Constructor, Destructor and Copy-Methods
	TmtcGenerator (void)
	Creates an emtpy MtcSystem. More...

	TmtcGenerator (const TmtcGenerator &rOtherGen)
	Creates an mtcgenerator from another mtcgenerator - copy constructor: More...

	TmtcGenerator (const vGenerator &rOtherGen)
	Creates an mtcgenerator from another generator - copy constructor. More...

	TmtcGenerator (const std::string &rFileName)
	Constructs an MtcSystem from file. More...

	~TmtcGenerator (void)
	Destructor for MtcSystem. More...

virtual TmtcGenerator *	New (void) const
	Construct on heap. More...

virtual TmtcGenerator *	Copy (void) const
	Construct copy on heap. More...

virtual TmtcGenerator &	Assign (const Type &rSrc)
	Assignment. More...

virtual TmtcGenerator &	operator= (const TmtcGenerator &rOtherGen)
	Assignment operator (uses Assign) More...

Color Symbol Table
SymbolTable *	GlobalColorSymbolTablep (void) const
	Get Pointer to global ColorSymbolTable. More...

SymbolTable *	ColorSymbolTablep (void) const
	Get Pointer to ColorSymbolTable currently used by this MtcSystem. More...

void	ColorSymbolTable (SymbolTable *pSymTab)
	Set ColorSymbolTable to be used by this MtcSystem. More...

void	ColorSymbolTable (const TmtcGenerator &rOtherGen)
	Set ColorSymbolTable as given by rOtherGen. More...

Editing Colored States
Idx	InsColoredState (const std::string &rStateName, const std::string &rColorName)
	Create a new named state and set the color rColorName. More...

Idx	InsColoredState (const std::string &rStateName, Idx colorIndex)
	Create a new named state and set the color colorIndex. More...

Idx	InsColoredState (const std::string &rStateName, const ColorSet &rColors)
	Create a new named state and set the colors from rColors. More...

Idx	InsColoredState (const ColorSet &rColors)
	Create a new unnamed state and set the colors from rColors. More...

Idx	InsColor (Idx stateIndex, const std::string &rColorName)
	Insert a color by name into an existing state. More...

void	InsColor (Idx stateIndex, Idx colorIndex)
	Insert a color by index into an existing state. More...

void	InsColors (Idx stateIndex, const ColorSet &rColors)
	Insert multiple colors from a color set into an existing state. More...

void	DelColor (Idx stateIndex, const std::string &rColorName)
	Remove color by name from an existing state specified by index. More...

void	DelColor (Idx stateIndex, Idx colorIndex)
	Remove color by index form an existing state specified by index. More...

void	DelColor (const std::string &rColorName)
	Remove color by name from all states. More...

void	DelColor (Idx colorIndex)
	Remove color by index from all states. More...

void	ClrColors (Idx stateIndex)
	Remove all colors from a particular state. More...

void	ClearStateAttributes ()
	Clear all the generator's state attributes. More...

Analyse Colored States and State Colors
void	Colors (ColorSet &rColors) const
	Insert all colors used in the generator to a given ColorSet. More...

ColorSet	Colors (void) const
	Returns a color set containing all the generator's colors. More...

const ColorSet &	Colors (Idx stateIndex) const
	Return a color set which contains all colors of one state. More...

StateSet	ColoredStates (Idx colorIndex) const
	Returns a state set containing all states that are colored with the color given by index. More...

StateSet	ColoredStates (const std::string &rColorName) const
	Returns a state set containing all states that are colored with the color given by name. More...

StateSet	ColoredStates () const
	Returns a state set containing all colored states of the MtcSystem. More...

StateSet	UncoloredStates () const
	Returns a state set containing all states that are not colored. More...

bool	ExistsColor (Idx colorIndex) const
	Check if color exists in generator. More...

bool	ExistsColor (const std::string &rColorName) const
	Check if color exists in generator. More...

bool	ExistsColor (Idx stateIndex, Idx colorIndex) const
	Check if color exists in a given state of the MtcSystem. More...

bool	IsColored (void) const
	Check if there is at least one colored state in the MtcSystem. More...

bool	IsColored (Idx stateIndex) const
	Check if the given state is colored or not. More...

Symbol Table
void	DelColorName (Idx colorIndex)
	Finally deletes a color name and its index from the currently used symbol table. More...

void	CheckSymbolTable (Idx colorIndex)
	Delete the given color from the symbol table if it is not used anymore in the generator by calling DelColorName. More...

void	CheckSymbolTable (ColorSet &rColors)
	Delete all colors from the given color set from the color symbol table by calling DelColorName if they are not used anymore. More...

std::string	ColorName (Idx colorIndex) const
	Look up the color name for a given color index. More...

Idx	ColorIndex (const std::string &rColorName) const
	Look up the color index for a given color name. More...

Output Methods
virtual void	DotWrite (const std::string &rFileName) const
	Writes generator to dot input format. More...

std::string	CStr (Idx index) const
	Return pretty printable color name for index. More...

Reachability
StateSet	StronglyCoaccessibleSet (void) const
	Generate a state set with all strongly coaccessible states. More...

bool	StronglyCoaccessible (void)
	Make generator strongly coaccessible. More...

bool	IsStronglyCoaccessible (void) const
	Check if MtcSystem is strongly coaccessible. More...

StateSet	StronglyTrimSet (void) const
	Generate a state set with all the strongly trim generator's states. More...

bool	StronglyTrim (void)
	Make generator strongly trim. More...

bool	IsStronglyTrim (void) const
	Check if the MtcSystem is strongly trim. More...

Further Methods
void	NewColorSymbolTable ()
	Insert a new local color symbol table. More...

std::map< Idx, ColorSet >	StateColorMap (void) const
	Return a color map with state indices and their corresponding colors. More...

Public Member Functions inherited from faudes::TcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
	TcGenerator (void)
	Creates an emtpy System object. More...

	TcGenerator (const vGenerator &rOtherGen)
	System from a std Generator. More...

	TcGenerator (const TcGenerator &rOtherGen)
	System from a System. More...

	TcGenerator (const std::string &rFileName)
	construct a System from file More...

virtual const Type *	Cast (const Type *pOther) const
	Type test. More...

TcGenerator	NewCGen (void) const
	Construct on stack. More...

virtual TcGenerator &	operator= (const TcGenerator &rOtherGen)
	Assignment operator (uses Assign) More...

void	InsControllableEvent (Idx index)
	Add an existing controllable event to generator. More...

Idx	InsControllableEvent (const std::string &rName)
	Add new named controllable event to generator. More...

void	InsUncontrollableEvent (Idx index)
	Add an existing uncontrollable event to generator. More...

Idx	InsUncontrollableEvent (const std::string &rName)
	Add new named uncontrollable event to generator. More...

void	SetControllable (Idx index)
	Mark event controllable (by index) More...

void	SetControllable (const std::string &rName)
	Mark event controllable (by name) More...

void	SetControllable (const EventSet &rEvents)
	Mark set of events controllable (by index) More...

void	ClrControllable (Idx index)
	Mark event uncontrollable (by index) More...

void	ClrControllable (const std::string &rName)
	Mark event uncontrollable (by name) More...

void	ClrControllable (const EventSet &rEvents)
	Mark set of events uncontrollable (by index) More...

bool	Controllable (Idx index) const
	Is event controllable (by index) More...

bool	Controllable (const std::string &rName) const
	Is event controllable (by name) More...

EventSet	ControllableEvents (void) const
	Get EventSet with controllable events. More...

EventSet	UncontrollableEvents (void) const
	Get EventSet with uncontrollable events. More...

void	InsObservableEvent (Idx index)
	Add an existing observable event to generator. More...

Idx	InsObservableEvent (const std::string &rName)
	Add new named observable event to generator. More...

void	InsUnobservableEvent (Idx index)
	Add an existing unobservable event to generator. More...

Idx	InsUnobservableEvent (const std::string &rName)
	Add new named unobservable event to generator. More...

void	SetObservable (Idx index)
	Mark event observable (by index) More...

void	SetObservable (const std::string &rName)
	Mark event observable (by name) More...

void	SetObservable (const EventSet &rEvents)
	Mark set of events observable. More...

void	ClrObservable (Idx index)
	Mark event unobservable (by index) More...

void	ClrObservable (const std::string &rName)
	Mark event unobservable (by name) More...

void	ClrObservable (const EventSet &rEvents)
	Mark set of events unobservable. More...

bool	Observable (Idx index) const
	Is event observable (by index) More...

bool	Observable (const std::string &rName) const
	Is event observable (by name) More...

EventSet	ObservableEvents (void) const
	Get EventSet with observable events. More...

EventSet	UnobservableEvents (void) const
	Get EventSet with unobservable events. More...

void	InsForcibleEvent (Idx index)
	Add an existing forcible event to generator. More...

Idx	InsForcibleEvent (const std::string &rName)
	Add new named forcible event to generator. More...

void	InsUnforcibleEvent (Idx index)
	Add an existing unforcible event to generator. More...

Idx	InsUnforcibleEvent (const std::string &rName)
	Add new named unforcible event to generator. More...

void	SetForcible (Idx index)
	Mark event forcible (by index) More...

void	SetForcible (const std::string &rName)
	Mark event forcible (by name) More...

void	SetForcible (const EventSet &rEvents)
	Mark set of events forcible. More...

void	ClrForcible (Idx index)
	Mark event unforcible (by index) More...

void	ClrForcible (const std::string &rName)
	Mark event unforcible (by name) More...

void	ClrForcible (const EventSet &rEvents)
	Mark set of events unforcible. More...

bool	Forcible (Idx index) const
	Is event forcible (by index) More...

bool	Forcible (const std::string &rName) const
	Is event forcible (by name) More...

EventSet	ForcibleEvents (void) const
	Get EventSet with forcible events. More...

EventSet	UnforcibleEvents (void) const
	Get EventSet with unforcible events. More...

void	InsHighlevelEvent (Idx index)
	Add an existing abstraction event to generator. More...

Idx	InsHighlevelEvent (const std::string &rName)
	Add new named abstraction event to generator. More...

void	InsLowlevelEvent (Idx index)
	Add an existing low-level event to generator. More...

Idx	InsLowlevelEvent (const std::string &rName)
	Add new named low-level event to generator. More...

void	SetHighlevel (Idx index)
	Mark event as highlevel event (by index) More...

void	SetHighlevel (const std::string &rName)
	Mark event as highlevel event (by name) More...

void	SetHighlevel (const EventSet &rEvents)
	Mark set of events as high-level events. More...

void	SetLowlevel (Idx index)
	Mark event as low-level event (by index) More...

void	SetLowlevel (const std::string &rName)
	Mark event as low-level event (by name) More...

void	SetLowlevel (const EventSet &rEvents)
	Mark set of events as low-level events. More...

bool	Highlevel (Idx index) const
	Test for high-level event (by index) More...

bool	Highlevel (const std::string &rName) const
	Test for high-level event (by name) More...

bool	Lowlevel (Idx index) const
	Test for low-level event (by index) More...

bool	Lowlevel (const std::string &rName) const
	Test for low-level event (by name) More...

EventSet	HighlevelEvents (void) const
	Get EventSet of all high-level events. More...

EventSet	LowlevelEvents (void) const
	Get EventSet of all low-level events. More...

Public Member Functions inherited from faudes::TaGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
	TaGenerator (void)
	Construct an emtpy Generator. More...

	TaGenerator (const TaGenerator &rOtherGen)
	Copy-constructor (from TaGenerator, incl attributes) More...

	TaGenerator (const vGenerator &rOtherGen)
	Copy-constructor (from vGenerator, set attributes to default) More...

	TaGenerator (const std::string &rFileName)
	Construct from file. More...

virtual TaGenerator	NewAGen (void) const
	Construct on stack. More...

virtual	~TaGenerator (void)
	Destructor. More...

virtual TaGenerator &	operator= (const TaGenerator &rOtherGen)
	Assignment operator (uses Assign(Generator&) ) More...

virtual void	Move (TaGenerator &rGen)
	Destructive copy to other TaGenerator Copy method with increased performance at the cost of invalidating the source data. More...

virtual void	Move (Generator &rGen)
	Destructive copy to other Generator. More...

bool	Valid (void) const
	Check if generator is valid. More...

virtual void	Clear (void)
	Clear generator data. More...

const TaEventSet< EventAttr > &	Alphabet (void) const
	Return const reference to alphabet. More...

const TaStateSet< StateAttr > &	States (void) const
	Return reference to state set. More...

const ATransSet &	TransRel (void) const
	Return reference to transition relation. More...

void	TransRel (TransSetX1EvX2 &res) const
	Get copy of trantision relation sorted by other compare operator, e.g. More...

void	TransRel (TransSetEvX1X2 &res) const

void	TransRel (TransSetEvX2X1 &res) const

void	TransRel (TransSetX2EvX1 &res) const

void	TransRel (TransSetX2X1Ev &res) const

void	TransRel (TransSetX1X2Ev &res) const

bool	InsEvent (Idx index)
	Add an existing event to alphabet by index. More...

Idx	InsEvent (const std::string &rName)
	Add named event to generator. More...

bool	InsEvent (Idx index, const EventAttr &rAttr)
	Add an existing event to alphabet by index, incl. More...

Idx	InsEvent (const std::string &rName, const EventAttr &rAttr)
	Add named event with attribute to generator. More...

void	InjectAlphabet (const EventSet &rNewalphabet)
	Set mpAlphabet without consistency check. More...

void	InjectAlphabet (const TaEventSet< EventAttr > &rNewalphabet)
	Set mpAlphabet without consistency check. More...

Idx	InsState (void)
	Add new anonymous state to generator. More...

Idx	InsState (const StateAttr &attr)
	Add new anonymous state with attribute to generator. More...

bool	InsState (Idx index)
	Add (perhaps new) state to generator. More...

Idx	InsState (const std::string &rName)
	Add new named state to generator. More...

Idx	InsState (const std::string &rName, const StateAttr &attr)
	Add new named state with attribute to generator. More...

bool	InsState (Idx index, const StateAttr &attr)
	Add (perhaps new) state with attribute to generator. More...

void	InjectStates (const StateSet &rNewStates)
	Inject a complete state set without consistency checks. More...

void	InjectStates (const TaStateSet< StateAttr > &rNewStates)
	Inject a complete state set without consistency checks. More...

bool	SetTransition (Idx x1, Idx ev, Idx x2)
	Add a transition to generator by indices. More...

bool	SetTransition (const std::string &rX1, const std::string &rEv, const std::string &rX2)
	Add a transition to generator by names. More...

bool	SetTransition (const Transition &rTransition)
	Add a transition to generator. More...

bool	SetTransition (const Transition &rTransition, const TransAttr &rAttr)
	Add a transition with attribute to generator. More...

void	InjectTransRel (const TransSet &rNewtransrel)
	Set transition relation without consistency check. More...

void	InjectTransRel (const ATransSet &rNewtransrel)
	Set transition relation without consistency check. More...

void	EventAttribute (Idx index, const EventAttr &rAttr)
	Set attribute for existing event. More...

void	EventAttribute (Idx index, const Type &rAttr)
	Set attribute for existing event. More...

const EventAttr &	EventAttribute (Idx index) const
	Event attribute lookup. More...

const EventAttr &	EventAttribute (const std::string &rName) const
	Event attribute lookup. More...

EventAttr *	EventAttributep (Idx index)
	Event attribute pointer (to access Attribute methods) note: may insert explicit default attribute. More...

EventAttr *	EventAttributep (const std::string &rName)
	Event attribute pointer (to access Attribute methods) note: may insert explicit default attribute. More...

void	StateAttribute (Idx index, const StateAttr &rAttr)
	Set attribute for existing state. More...

void	StateAttribute (Idx index, const Type &rAttr)
	Set attribute for existing state. More...

const StateAttr &	StateAttribute (Idx index) const
	State attribute lookup. More...

StateAttr *	StateAttributep (Idx index)
	State attribute pointer (to access Attribute methods) note: may insert explicit default attribute. More...

void	TransAttribute (const Transition &rTrans, const TransAttr &rAttr)
	Set attribute for existing transition. More...

void	TransAttribute (const Transition &rTrans, const Type &rAttr)
	Set attribute for existing transition. More...

const TransAttr &	TransAttribute (const Transition &rTrans) const
	Get attribute for existing transition. More...

TransAttr *	TransAttributep (const Transition &rTrans)
	Get attribute pointer for existing transition note: may insert explicit default attribute. More...

void	GlobalAttribute (const GlobalAttr &rAttr)
	Set global attribute. More...

void	GlobalAttribute (const Type &rAttr)
	Set global attribute. More...

const GlobalAttr &	GlobalAttribute (void) const
	Get global attribute ref. More...

GlobalAttr *	GlobalAttributep (void)
	Get global attribute pointer. More...

Public Member Functions inherited from faudes::vGenerator
	vGenerator (void)
	Default constructor. More...

	vGenerator (const vGenerator &rOtherGen)
	Copy-constructror. More...

	vGenerator (const std::string &rFileName)
	Construct from file. More...

virtual	~vGenerator (void)
	Destructor. More...

virtual vGenerator &	AssignWithoutAttributes (const vGenerator &rGen)
	Copy from other vGenerator, ignore attributes. More...

virtual vGenerator &	operator= (const vGenerator &rOtherGen)
	Assignment operator (uses Assign method) More...

virtual void	Version (const std::string &rVersion, vGenerator &rResGen) const
	Create another version of this generator. More...

virtual void	Version (Idx version, vGenerator &rResGen) const
	Create another version of this generator. More...

virtual void	Version (const std::string &rPattern, const std::string &rReplacement, vGenerator &rResGen) const
	Create another version of this generator. More...

void	Name (const std::string &rName)
	Set the generator's name. More...

const std::string &	Name (void) const
	Get generator's name. More...

void	ClearStates (void)
	Clear all states and transitions, maintain alphabet. More...

Idx	AlphabetSize (void) const
	Get number of events in alphabet. More...

Idx	Size (void) const
	Get generator size (number of states) More...

Idx	TransRelSize (void) const
	Get number of transitions. More...

Idx	InitStatesSize (void) const
	Get number of initial states. More...

Idx	MarkedStatesSize (void) const
	Get number of marked states. More...

bool	Empty (void) const
	Check if generator is empty (no states) More...

bool	AlphabetEmpty (void) const
	Check if alphabet is Empty. More...

bool	TransRelEmpty (void) const
	Check if transition relation is empty. More...

bool	InitStatesEmpty (void) const
	Check if set of initial states are empty. More...

bool	MarkedStatesEmpty (void) const
	Check if set of marked states are empty. More...

SymbolTable *	EventSymbolTablep (void) const
	Get Pointer to EventSymbolTable currently used by this vGenerator. More...

virtual void	EventSymbolTablep (SymbolTable *pSymTab)
	Set EventSymbolTable to be used by this vGenerator. More...

virtual void	EventSymbolTablep (const vGenerator &rOtherGen)
	Set EventSymbolTable as given by rOtherGen. More...

EventSet	NewEventSet (void) const
	Create EventSet with generator's EventSymbolTable (on stack). More...

EventSet *	NewEventSetp (void) const
	Create EventSet with generator's EventSymbolTable (on heap). More...

Idx	EventIndex (const std::string &rName) const
	Event index lookup. More...

std::string	EventName (Idx index) const
	Event name lookup. More...

void	EventName (Idx index, const std::string &rName)
	Set name for existing event. More...

std::string	UniqueEventName (const std::string &rName) const
	Create a new unique symbolic event name. More...

bool	EventRename (Idx event, const std::string &rNewName)
	Rename event in this generator. More...

bool	EventRename (const std::string &rOldName, const std::string &rNewName)
	Rename event in this generator. More...

const SymbolTable &	StateSymbolTable (void) const
	Get StateSymbolTable. More...

void	StateSymbolTable (const SymbolTable &rSymTab)
	Set StateSymbolTable. More...

Idx	StateIndex (const std::string &rName) const
	State index lookup. More...

std::string	StateName (Idx index) const
	State name lookup. More...

void	StateName (Idx index, const std::string &rName)
	Set name of state. More...

void	ClearStateNames (void)
	Remove all names from generator's StateSymbolTable. More...

void	ClrStateName (Idx index)
	Clear name for individual state. More...

void	ClrStateName (const std::string &rName)
	Clear name for individual state. More...

bool	StateNamesEnabled (void) const
	Whether libFAUEDS functions are requested to generate state names. More...

void	StateNamesEnabled (bool flag)
	Enable/disable libFAUEDS functions to automatically generate state names. More...

void	SetDefaultStateNames (void)
	Assign each state a default name based on its index. More...

void	EnforceStateNames (const std::string &rTemplate)
	For all states without a symbolic name, assign a name based on suggested template and the index. More...

std::string	UniqueStateName (const std::string &rName) const
	Create a new unique symbolic state name. More...

EventSet::Iterator	AlphabetBegin (void) const
	Iterator to Begin() of alphabet. More...

EventSet::Iterator	AlphabetEnd (void) const
	Iterator to End() of alphabet. More...

bool	ExistsEvent (Idx index) const
	Test existence of event in alphabet. More...

bool	ExistsEvent (const std::string &rName) const
	Test existence of event in alphabet. More...

EventSet::Iterator	FindEvent (Idx index) const
	Returns a iterator to event index in alphabet. More...

EventSet::Iterator	FindEvent (const std::string &rName) const
	Returns a iterator to event index in alphabet. More...

const EventSet &	Alphabet (void) const
	Return const reference to alphabet. More...

StateSet::Iterator	StatesBegin (void) const
	Iterator to Begin() of state set. More...

StateSet::Iterator	StatesEnd (void) const
	Iterator to End() of state set. More...

bool	ExistsState (Idx index) const
	Test existence of state in state set. More...

bool	ExistsState (const std::string &name) const
	Test existence of state in state set. More...

StateSet::Iterator	FindState (Idx index) const
	Returns a iterator to state index in state set. More...

StateSet::Iterator	FindState (const std::string &rName) const
	Returns a iterator to state with specified name. More...

const StateSet &	States (void) const
	Return reference to state set. More...

Idx	InitState (void) const
	Return initial state. More...

StateSet::Iterator	InitStatesBegin (void) const
	Iterator to Begin() of mInitStates. More...

StateSet::Iterator	InitStatesEnd (void) const
	Iterator to End() of mInitStates. More...

bool	ExistsInitState (Idx index) const
	Test existence of state in mInitStates. More...

StateSet::Iterator	FindInitState (Idx index) const
	Iterator to state index in mInitStates. More...

const StateSet &	InitStates (void) const
	Const ref to initial states. More...

StateSet::Iterator	MarkedStatesBegin (void) const
	Iterator to Begin() of mMarkedStates. More...

StateSet::Iterator	MarkedStatesEnd (void) const
	Iterator to End() of mMarkedStates. More...

bool	ExistsMarkedState (Idx index) const
	Test existence of state in mMarkedStates. More...

StateSet::Iterator	FindMarkedState (Idx index) const
	Returns a iterator to state index in mMarkedStates. More...

const StateSet &	MarkedStates (void) const
	Return const ref of marked states. More...

TransSet::Iterator	TransRelBegin (void) const
	Iterator to Begin() of transition relation. More...

TransSet::Iterator	TransRelEnd (void) const
	Iterator to End() of transition relation. More...

TransSet::Iterator	TransRelBegin (Idx x1) const
	Iterator to begin of transitions with x1 as predecessor state. More...

TransSet::Iterator	TransRelEnd (Idx x1) const
	iterator to end of transitions with x1 as predecessor state. More...

TransSet::Iterator	TransRelBegin (Idx x1, Idx ev) const
	iterator to begin of transitions with x1 as predecessor state and event ev. More...

TransSet::Iterator	TransRelEnd (Idx x1, Idx ev) const
	Iterator to end of transitions with x1 as predecessor state and event ev. More...

TransSet::Iterator	FindTransition (const std::string &rX1, const std::string &rEv, const std::string &rX2) const
	iterator to transition given by x1, ev, x2 More...

TransSet::Iterator	FindTransition (Idx x1, Idx ev, Idx x2) const
	Iterator to transition given by x1, ev, x2. More...

TransSet::Iterator	FindTransition (const Transition &rTrans) const
	Iterator to transition. More...

bool	ExistsTransition (const std::string &rX1, const std::string &rEv, const std::string &rX2) const
	Test for transition given by x1, ev, x2. More...

bool	ExistsTransition (Idx x1, Idx ev, Idx x2) const
	Test for transition given by x1, ev, x2. More...

bool	ExistsTransition (const Transition &rTrans) const
	test for transition More...

bool	ExistsTransition (Idx x1, Idx ev) const
	Test for transition given by x1, ev. More...

bool	ExistsTransition (Idx x1) const
	Test for transition given by x1. More...

const TransSet &	TransRel (void) const
	Return reference to transition relation. More...

void	TransRel (TransSetX1EvX2 &res) const
	Get copy of trantision relation sorted by other compare operator, e.g. More...

void	TransRel (TransSetEvX1X2 &res) const

void	TransRel (TransSetEvX2X1 &res) const

void	TransRel (TransSetX2EvX1 &res) const

void	TransRel (TransSetX2X1Ev &res) const

void	TransRel (TransSetX1X2Ev &res) const

Transition	TransitionByNames (const std::string &rX1, const std::string &rEv, const std::string &rX2) const
	Convebience function. More...

bool	InsEvent (Idx index)
	Add an existing event to alphabet by index. More...

Idx	InsEvent (const std::string &rName)
	Add named event to generator. More...

void	InsEvents (const EventSet &events)
	Add new named events to generator. More...

bool	DelEvent (Idx index)
	Delete event from generator by index. More...

bool	DelEvent (const std::string &rName)
	Delete event from generator by name. More...

void	DelEvents (const EventSet &rEvents)
	Delete a set of events from generator. More...

bool	DelEventFromAlphabet (Idx index)
	Delete event from alphabet without consistency check. More...

void	InjectAlphabet (const EventSet &rNewalphabet)
	Set mpAlphabet without consistency check. More...

void	RestrictAlphabet (const EventSet &rNewalphabet)
	Restricts mpAlphabet incl removing resp. More...

Idx	InsState (void)
	Add new anonymous state to generator. More...

bool	InsState (Idx index)
	Add (perhaps new) state to generator. More...

Idx	InsState (const std::string &rName)
	Add new named state to generator. More...

void	InsStates (const StateSet &rStates)
	Add anonymous states to generator. More...

bool	DelState (Idx index)
	Delete a state from generator by index. More...

bool	DelState (const std::string &rName)
	Delete a state from generator by name. More...

void	DelStates (const StateSet &rDelStates)
	Delete a set of states Cleans mpStates, mInitStates, mMarkedStates, mpTransrel, and mpStateSymboltable. More...

bool	DelStateFromStates (Idx index)
	Delete a state from generator without consistency check. More...

StateSet::Iterator	DelStateFromStates (StateSet::Iterator pos)
	Delete a state from generator without consistency check. More...

void	RestrictStates (const StateSet &rStates)
	Restrict states Cleans mpStates, mInitStates, mMarkedStates, mpTransrel, and mpStateSymboltable. More...

void	InjectState (Idx index)
	Inject an existing state index into generators mStates Use with care! For use in performance optimized functions. More...

void	InjectStates (const StateSet &rNewStates)
	Inject a complete state set without consistency checks (without attributes) More...

Idx	InsInitState (void)
	Create new anonymous state and set as initial state. More...

bool	InsInitState (Idx index)
	Add (perhaps new) state to generator and turn it into a initial state. More...

Idx	InsInitState (const std::string &rName)
	Create a new named state and set as initial state. More...

void	InsInitStates (const StateSet &rStates)
	Add (perhaps new) anonymous initial states to generator More...

Idx	InsMarkedState (void)
	Create new anonymous state and set as marked state. More...

bool	InsMarkedState (Idx index)
	Add (perhaps new) state to generator and turn it into a marked state. More...

Idx	InsMarkedState (const std::string &rName)
	Create a new named state and set as marked state. More...

void	InsMarkedStates (const StateSet &rStates)
	Add (perhaps new) anonymous initial states to generator More...

void	SetInitState (Idx index)
	Set an existing state as initial state by index. More...

void	SetInitState (const std::string &rName)
	Set an existing state as initial state by name. More...

void	InjectInitStates (const StateSet &rNewInitStates)
	Replace mInitStates with StateSet given as parameter without consistency checks. More...

void	ClrInitState (Idx index)
	Unset an existing state as initial state by index. More...

void	ClrInitState (const std::string &rName)
	Unset an existing state as initial state by name. More...

StateSet::Iterator	ClrInitState (StateSet::Iterator pos)
	Unset an existing state as initial state by iterator. More...

void	ClearInitStates (void)
	Clear all mInitStates. More...

void	SetMarkedState (Idx index)
	Set an existing state as marked state by index. More...

void	SetMarkedState (const std::string &rName)
	Set an existing state as marked state by name. More...

void	ClrMarkedState (Idx index)
	Unset an existing state as marked state by index. More...

void	ClrMarkedState (const std::string &rName)
	Unset an existing state as marked state by name. More...

StateSet::Iterator	ClrMarkedState (StateSet::Iterator pos)
	Unset an existing state as marked state by iterator. More...

void	ClearMarkedStates (void)
	Clear all marked states. More...

void	InjectMarkedStates (const StateSet &rNewMarkedStates)
	Replace mMarkedStates with StateSet given as parameter without consistency checks. More...

bool	SetTransition (Idx x1, Idx ev, Idx x2)
	Add a transition to generator by indices. More...

bool	SetTransition (const std::string &rX1, const std::string &rEv, const std::string &rX2)
	Add a transition to generator by names. More...

bool	SetTransition (const Transition &rTransition)
	Add a transition to generator. More...

void	ClrTransition (Idx x1, Idx ev, Idx x2)
	Remove a transition by indices. More...

void	ClrTransition (const Transition &rTrans)
	Remove a transition by transition object. More...

TransSet::Iterator	ClrTransition (TransSet::Iterator it)
	Remove a transition by iterator. More...

void	ClrTransitions (Idx x1, Idx ev)
	Remove a transitions by state and event. More...

void	ClrTransitions (Idx x1)
	Remove a transitions by state. More...

void	ClearTransRel (void)
	Clear all transitions. More...

void	InjectTransition (const Transition &rTrans)
	Set transition without consistency check. More...

void	InjectTransRel (const TransSet &rNewtransrel)
	Set transition relation without consistency check (no attributes) More...

virtual void	ClearAttributes (void)
	Clear Attributes. More...

virtual bool	UpdateAttributes (void)
	Updates internal attributes. More...

virtual void	ClearEventAttributes (void)
	Clear event attributes. More...

virtual void	ClrEventAttribute (Idx index)
	Clear attribute for existing event. More...

virtual void	EventAttributes (const EventSet &rEventSet)
	Set attributes for existing events. More...

virtual void	ClrStateAttribute (Idx index)
	Clear attribute for existing state. More...

virtual void	ClearTransAttributes (void)
	Clear transition attributes. More...

virtual void	ClrTransAttribute (const Transition &rTrans)
	Clear attribute for existing transition. More...

virtual void	ClearGlobalAttribute (void)
	Clear global attribute. More...

virtual void	GlobalAttributeTry (const Type &rAttr)
	Set global attribute. More...

StateSet	AccessibleSet (void) const
	Compute set of accessible states. More...

bool	Accessible (void)
	Make generator accessible. More...

bool	IsAccessible (void) const
	Check if generator is accessible. More...

StateSet	CoaccessibleSet (void) const
	Compute set of Coaccessible states. More...

bool	Coaccessible (void)
	Make generator Coaccessible. More...

bool	IsCoaccessible (void) const
	Check if generator is Coaccessible. More...

StateSet	BlockingStates (void) const
	Compute set of blocking states. More...

StateSet	TerminalStates (void) const
	Compute set of terminal states. More...

StateSet	TerminalStates (const StateSet &rStates) const
	Compute set of terminal states. More...

bool	IsComplete (void) const
	Check if generator is complete. More...

bool	IsComplete (const StateSet &rStates) const
	Check if generator is complete. More...

bool	IsComplete (const EventSet &rSigmaO) const
	Check if generator is complete w.r.t. More...

bool	Complete (void)
	Make generator Complete. More...

bool	Complete (const EventSet &rSigmaO)
	Make generator Complete w.r.t. More...

StateSet	TrimSet (void) const
	Compute set of trim states. More...

bool	Trim (void)
	Make generator trim. More...

bool	IsTrim (void) const
	Check if generator is trim. More...

bool	OmegaTrim (void)
	Make generator omega-trim. More...

bool	IsOmegaTrim (void) const
	Check if generator is omega-trim. More...

EventSet	UsedEvents (void) const
	Return used events (executed in transitions) More...

EventSet	UnusedEvents (void) const
	Return unused events. More...

void	MinimizeAlphabet (void)
	Set the alphabet to used events. More...

EventSet	ActiveEventSet (Idx x1) const
	Return active event set at state x1. More...

TransSet	ActiveTransSet (Idx x1) const
	Return active transition set at state x1. More...

StateSet	TransRelStates (void) const
	Return the states covered by transitions. More...

Idx	SuccessorState (Idx x1, Idx ev) const
	Return the successor state of state x1 with event ev. More...

StateSet	SuccessorStates (Idx x1) const
	Return the successor states of state x1. More...

StateSet	SuccessorStates (Idx x1, Idx ev) const
	Return the successor states of state x1 with event ev. More...

bool	IsDeterministic (void) const
	Check if generator is deterministic. More...

void	SetMinStateIndexMap (void) const
	Set minimal index map for file io of generator states. More...

void	ClearMinStateIndexMap (void) const
	Clear minimal index map for 1:1 file io. More...

Idx	MinStateIndex (Idx index) const
	Get state index as is it will be written to file. More...

void	MinStateIndex (void)
	Re-enumerate states. More...

Idx	MaxStateIndex (void) const
	Get maximum state index used in this generator. More...

const std::map< Idx, Idx > &	MinStateIndexMap (void) const
	Get state index translation map. More...

std::string	EStr (Idx index) const
	Pretty printable event name for index (eg for debugging). More...

std::string	SStr (Idx index) const
	Return pretty printable state name for index (eg for debugging) More...

std::string	TStr (const Transition &rTrans) const
	Return pretty printable transition (eg for debugging) More...

void	GraphWrite (const std::string &rFileName, const std::string &rOutFormat="", const std::string &rDotExec="dot") const
	Produce graphical representation of this generator. More...

bool	operator< (const vGenerator &rOtherGen) const
	Order for sorting containers of generators. More...

void	WriteAlphabet (void) const
	Write generators alphabet to console. More...

std::string	AlphabetToString (void) const
	Write generators alphabet to string. More...

void	WriteAlphabet (TokenWriter &rTw) const
	Write generators alphabet to tokenwriter. More...

void	WriteStateSet (const StateSet &rStateSet) const
	Write a stateset to console (no re-indexing). More...

std::string	StateSetToString (const StateSet &rStateSet) const
	Write a stateset to string (no re-indexing). More...

std::string	StateSetToText (const StateSet &rStateSet) const
	Write a stateset to formated text (no re-indexing). More...

void	WriteStateSet (TokenWriter &rTw, const StateSet &rStateSet) const
	Write a stateset to TokenWriter. More...

void	DWriteStateSet (TokenWriter &rTw, const StateSet &rStateSet) const
	Write a stateset to TokenWriter (debug version, no re-indexing) More...

std::string	StatesToString (void) const
	Write stateset of this generator to a string (no re-indexing) More...

std::string	StatesToText (void) const
	Write stateset of this generator to formated text (no re-indexing) More...

std::string	MarkedStatesToString (void) const
	Write set of marked states to a string (no re-indexing) More...

std::string	InitStatesToString (void) const
	Write set of initial states to a string (no re-indexing) More...

void	WriteTransRel (void) const
	Write transition relation to console (no re-indexing) More...

std::string	TransRelToString (void) const
	Write transition relation to string (no re-indexing) More...

std::string	TransRelToText (void) const
	Write transition relation to formated text (no re-indexing) More...

void	WriteTransRel (TokenWriter &rTw) const
	Write transition relation to tokenwriter. More...

void	DWriteTransRel (TokenWriter &rTw) const
	Write transition relation to tokenwriter (debug version) More...

virtual void	DDotWrite (const std::string &rFileName) const
	Writes generator to dot input format (no re-indexing). More...

virtual void	XDotWrite (const std::string &rFileName) const
	Writes generator to dot input format for export to VioLib. More...

void	ReadStateSet (TokenReader &rTr, const std::string &rLabel, StateSet &rStateSet) const
	Read a state set. More...

bool	ReindexOnWrite (void) const
	Test whether file-i/o uses minimal state indicees. More...

void	ReindexOnWrite (bool flag)
	Enable/disable minimal state indicees for file-i/o. More...

Public Member Functions inherited from faudes::Type
	Type (void)
	Constructor. More...

	Type (const Type &rType)
	Copy constructor. More...

virtual	~Type (void)
	Destructor. More...

virtual Type &	operator= (const Type &rSrc)
	Assign configurationdata from other object. More...

virtual bool	Equal (const Type &rOther) const
	Test equality of configuration data. More...

virtual bool	operator== (const Type &rOther) const
	Test equality of configuration data. More...

virtual bool	operator!= (const Type &rOther) const
	Test equality of configuration data. More...

virtual const std::string &	TypeName (void) const
	Get objects's type name. More...

void	Write (const Type *pContext=0) const
	Write configuration data to console. More...

void	Write (const std::string &pFileName, const std::string &rLabel="", const Type *pContext=0, std::ios::openmode openmode=std::ios::out\|std::ios::trunc) const
	Write configuration data to a file. More...

void	Write (const std::string &pFileName, std::ios::openmode openmode) const
	Write configuration data to a file. More...

void	Write (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data to TokenWriter. More...

virtual void	XWrite (const std::string &pFileName, const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data to an XML file. More...

void	XWrite (const Type *pContext=0) const
	Write configuration data in XML format to concole Note: this write function uses the virtual function DoXWrite(), to be reimplemented by derived classes. More...

void	XWrite (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data in XML format to TokenWriter. More...

std::string	ToString (const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data to a string. More...

std::string	ToText (const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data to a formated string. More...

void	DWrite (const Type *pContext=0) const
	Write configuration data to console, debugging format. More...

void	DWrite (const std::string &pFileName, const std::string &rLabel="", const Type *pContext=0, std::ios::openmode openmode=std::ios::out\|std::ios::trunc) const
	Write configuration data to a file, debugging format. More...

void	DWrite (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write configuration data in debug format to TokenWriter. More...

void	SWrite (TokenWriter &rTw) const
	Write statistics comment to TokenWriter. More...

void	SWrite (void) const
	Write statistics comment to console. More...

std::string	ToSText (void) const
	Write statistics to a string. More...

void	Read (const std::string &rFileName, const std::string &rLabel="", const Type *pContext=0)
	Read configuration data from file with label specified. More...

void	FromString (const std::string &rString, const std::string &rLabel="", const Type *pContext=0)
	Read configuration data from a string. More...

void	Read (TokenReader &rTr, const std::string &rLabel="", const Type *pContext=0)
	Read configuration data from TokenReader with label sepcified. More...

Protected Member Functions
void	DoAssign (const TmtcGenerator &rSrc)
	Assignment. More...

virtual void	DoSWrite (TokenWriter &rTw) const
	Token output, see Type::SWrite for public wrappers. More...

Protected Member Functions inherited from faudes::TaGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
virtual void	NewCore (void)
	Allocate my heap members (attribute dependent types) More...

virtual void	UpdateCore (void)
	Update my secondary pointers for new core. More...

void	DoAssign (const TaGenerator &rGen)
	Assignment. More...

Protected Member Functions inherited from faudes::vGenerator
virtual void	DeleteCore (void)
	Free my heap members (attribute dependent types) More...

void	ConfigureAttributeTypes (const AttributeVoid pNewGlobalPrototype, const StateSet pNewStatesPrototype, const EventSet pNewAlphabetPrototype, const TransSet pNewTransRelPrototype)
	Configure attribute types. More...

void	DoAssign (const vGenerator &rSrc)
	Assignment for matching type. More...

virtual void	DoRead (TokenReader &rTr, const std::string &rLabel="", const Type *pContext=0)
	Read generator object from TokenReader, see Type::Read for public wrappers. More...

virtual void	DoWrite (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write generator to TokenWriter, see Type::Write for public wrappers. More...

virtual void	DoDWrite (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write generator in debugging format to TokenWriter, see Type::DWrite for public wrappers. More...

virtual void	DoXWrite (TokenWriter &rTw, const std::string &rLabel="", const Type *pContext=0) const
	Write generator to TokenWriter, see Type::XWrite for public wrappers. More...

void	ReadAlphabet (TokenReader &rTr)
	Read the generator's alphabet from a TokenReader. More...

void	WriteStates (TokenWriter &rTw) const
	Write generators stateset to TokenWriter. More...

void	ReadStates (TokenReader &rTr)
	Read the generator's stateset from a TokenReader. More...

void	XReadStateSet (TokenReader &rTr, StateSet &rStateSet, const std::string &rLabel="") const
	Read a stateset from TokenReader in XML format. More...

void	ReadTransRel (const std::string &rFileName)
	Read the generator's transition relation from a file. More...

void	ReadTransRel (TokenReader &rTr)
	Read the generator's transition relation from a TokenReader. More...

void	XReadTransRel (TokenReader &rTr)
	Read the generator's transition relation from a TokenReader. More...

void	XWriteStateSet (TokenWriter &rTw, const StateSet &rStateSet, const std::string &rLabel="") const
	Write a stateset to TokenWriter in XML format. More...

void	XWriteTransRel (TokenWriter &rTw) const
	Write transition relation to tokenwriter in XML format. More...

Protected Member Functions inherited from faudes::Type
void	DoAssign (const Type &rSrc)
	Assign configuration data from other object. More...

bool	DoEqual (const Type &rOther) const
	Test equality of configuration data. More...

virtual const TypeDefinition *	TypeDefinitionp (void) const
	Get objects's type definition. More...

virtual Token	XBeginTag (const std::string &rLabel="", const std::string &rFallbackLabel="") const

Protected Attributes
SymbolTable *	mpColorSymbolTable
	Pointer to currently used symbol table. More...

Protected Attributes inherited from faudes::TaGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
TaNameSet< EventAttr > *	pAlphabet
	Alphabet, pointer with actual attribute type. More...

TaIndexSet< StateAttr > *	pStates
	State set, pointer with actual attribute type. More...

ATransSet *	pTransRel
	Transition relation, pointer with actual attribute type. More...

GlobalAttr *	pGlobalAttribute
	Global attribute, pointer with actual attribute type. More...

Protected Attributes inherited from faudes::vGenerator
std::string	mMyName
	Name of generator. More...

Idx	mId
	Number of generator. More...

SymbolTable	mStateSymbolTable
	State symbol table (local per Generator) More...

SymbolTable *	mpStateSymbolTable
	Pointer to State symbol table. More...

SymbolTable *	mpEventSymbolTable
	Pointer to Event symbol table. More...

bool	mStateNamesEnabled
	Automatic state names. More...

bool	mReindexOnWrite
	Reindex states on file-i/o. More...

EventSet *	mpAlphabet
	Pointer to alphabet (actual type depends on attributes) More...

StateSet *	mpStates
	Pointer to state set (actual type depends on attributes) More...

TransSet *	mpTransRel
	Pointer to ransition relation (actual type depends on attributes) More...

AttributeVoid *	mpGlobalAttribute
	Pointer to lobal attribute (actual type depends on attributes) More...

const EventSet *	pAlphabetPrototype
	Pointer to alphabet prototype (incl. More...

const StateSet *	pStatesPrototype
	Pointer to state set prototype (incl. More...

const TransSet *	pTransRelPrototype
	Pointer to transition relation prototype (incl. More...

const AttributeVoid *	pGlobalPrototype
	Pointer to global attribute prototype (configures global attribute type) More...

StateSet	mInitStates
	Initial states. More...

StateSet	mMarkedStates
	Marked states. More...

std::map< Idx, Idx >	mMinStateIndexMap
	Map State indices to consecutive indices. More...

Additional Inherited Members
Public Types inherited from faudes::TaGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
typedef TaTransSet< TransAttr >	ATransSet
	Convenience typdef for member transiton set. More...

Static Public Member Functions inherited from faudes::vGenerator
static SymbolTable *	GlobalEventSymbolTablep (void)
	Get Pointer to global EventSymbolTable. More...

static void	StateNamesEnabledDefault (bool flag)
	Sets the default for automatic state name generation. More...

static void	ReindexOnWriteDefault (bool flag)
	Enable/disable reindexing states for file-i/o. More...

static bool	ReindexOnWriteDefault (void)
	Enable/disable reindexing states for file-i/o. More...

Static Protected Member Functions inherited from faudes::TaGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
static const TaNameSet< EventAttr > &	AlphabetTaGen (void)
	Static default alphabet prototype (incl. More...

static const TaIndexSet< StateAttr > &	StatesTaGen (void)
	Static default state set prototype (incl. More...

static const ATransSet &	TransRelTaGen (void)
	Static default transition relation prototype (incl. More...

static const GlobalAttr &	GlobalTaGen (void)
	Static default global attribute prototype (configures global attribute type) More...

Static Protected Member Functions inherited from faudes::vGenerator
static const EventSet &	AlphabetVoid (void)
	Static default alphabet prototype (incl. More...

static const StateSet &	StatesVoid (void)
	Static default state set prototype (incl. More...

static const TransSet &	TransRelVoid (void)
	Static default transition relation prototype (incl. More...

static const AttributeVoid &	GlobalVoid (void)
	Static default global attribute prototype (configures global attribute type) More...

Static Protected Attributes inherited from faudes::vGenerator
static Idx	msObjectCount = 0
	Number of generator objects. More...

static bool	msStateNamesEnabledDefault = true
	Default for automatic statenames. More...

static bool	msReindexOnWriteDefault = false
	Default for automatic statenames. More...

Constructor & Destructor Documentation

◆ TmtcGenerator() [1/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::TmtcGenerator ( void )

Creates an emtpy MtcSystem.

doxygen group

Definition at line 799 of file mtc_generator.h.

◆ TmtcGenerator() [2/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::TmtcGenerator ( const TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > & rOtherGen )

Creates an mtcgenerator from another mtcgenerator - copy constructor:

If the other MtcSystem uses a local color symbol table, the new generator also creates a local symbol table. This new one is empty! If you use a local symbol table, you should implement a copy mechanism for the entries of the original generator's symbol table.

Parameters

rOtherGen Other mtcgenerator to copy

Definition at line 805 of file mtc_generator.h.

◆ TmtcGenerator() [3/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::TmtcGenerator ( const vGenerator & rOtherGen )

Creates an mtcgenerator from another generator - copy constructor.

Parameters

rOtherGen Other generator to copy

Definition at line 814 of file mtc_generator.h.

◆ TmtcGenerator() [4/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::TmtcGenerator ( const std::string & rFileName )

Constructs an MtcSystem from file.

Define FAUDES_CHECKED for consistency checks

Parameters

rFileName Filename

Exceptions

Exception

Opening/reading failed (ids 1, 50, 51)

Definition at line 821 of file mtc_generator.h.

◆ ~TmtcGenerator()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::~TmtcGenerator ( void )

inline

Destructor for MtcSystem.

Definition at line 103 of file mtc_generator.h.

Member Function Documentation

◆ Assign()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > & faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::Assign ( const Type & rSrc )

virtual

Assignment.

Parameters

rSrc	MtcSystem to copy from

Reimplemented from faudes::TcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >.

Definition at line 877 of file mtc_generator.h.

◆ CheckSymbolTable() [1/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::CheckSymbolTable ( ColorSet & rColors )

Delete all colors from the given color set from the color symbol table by calling DelColorName if they are not used anymore.

rColors must use the same symbol table as the MtcSystem!

Parameters

rColors Color set with all colors that will be deleted from symbol table if not used anymore

Exceptions

Exception

Symbol table mismatch (id 88)

Definition at line 1235 of file mtc_generator.h.

◆ CheckSymbolTable() [2/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::CheckSymbolTable ( Idx colorIndex )

Delete the given color from the symbol table if it is not used anymore in the generator by calling DelColorName.

Parameters

colorIndex Color which will be deleted from symbol table if not used anymore

Definition at line 1225 of file mtc_generator.h.

◆ ClearStateAttributes()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ClearStateAttributes ( void )

virtual

Clear all the generator's state attributes.

The current implementation also clears the color symbol table if it is local. This behaviour may change in future.

Reimplemented from faudes::vGenerator.

Definition at line 1620 of file mtc_generator.h.

◆ ClrColors()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ClrColors ( Idx stateIndex )

Remove all colors from a particular state.

If symbol table is local, unused colors are deleted from it, global symbol table stays untouched.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex State where colors should be removed

Exceptions

Exception

Index not member of set (id 200)

Definition at line 1153 of file mtc_generator.h.

◆ ColoredStates() [1/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColoredStates

Returns a state set containing all colored states of the MtcSystem.

Returns: State set containing colored states

Definition at line 1469 of file mtc_generator.h.

◆ ColoredStates() [2/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColoredStates ( const std::string & rColorName ) const

Returns a state set containing all states that are colored with the color given by name.

Parameters

rColorName Color whose corresponding states shall be returned

Returns: State set containing appropriate states

Definition at line 1463 of file mtc_generator.h.

◆ ColoredStates() [3/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColoredStates ( Idx colorIndex ) const

Returns a state set containing all states that are colored with the color given by index.

Parameters

colorIndex Color whose corresponding states shall be returned

Returns: State set containing appropriate states

Definition at line 1453 of file mtc_generator.h.

◆ ColorIndex()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColorIndex ( const std::string & rColorName ) const

Look up the color index for a given color name.

Parameters

rColorName

Returns: Color index

Definition at line 1283 of file mtc_generator.h.

◆ ColorName()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

std::string faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColorName ( Idx colorIndex ) const

Look up the color name for a given color index.

Parameters

colorIndex

Returns: Color name

Definition at line 1278 of file mtc_generator.h.

◆ Colors() [1/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::Colors ( ColorSet & rColors ) const

Insert all colors used in the generator to a given ColorSet.

doxygen group

Parameters

rColors Color set in which all colors of the generator will be inserted

Exceptions

Exception

Symbol table mismatch (id 88)

Definition at line 1180 of file mtc_generator.h.

◆ Colors() [2/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

const ColorSet & faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::Colors ( Idx stateIndex ) const

Return a color set which contains all colors of one state.

Returns: Color set with state's colors

Exceptions

Exception

Index not member of set (id 200)

Definition at line 1207 of file mtc_generator.h.

◆ Colors() [3/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

ColorSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::Colors ( void ) const

Returns a color set containing all the generator's colors.

Returns: Color set with generators colors

Definition at line 1196 of file mtc_generator.h.

◆ ColorSymbolTable() [1/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColorSymbolTable ( const TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > & rOtherGen )

Set ColorSymbolTable as given by rOtherGen.

Parameters

rOtherGen Other generator

Definition at line 910 of file mtc_generator.h.

◆ ColorSymbolTable() [2/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColorSymbolTable ( SymbolTable * pSymTab )

Set ColorSymbolTable to be used by this MtcSystem.

Note: the managemnt of local color symbol tables needs a re-design. Dont use thus feature.

Parameters

pSymTab Pointer to SymbolTable

Definition at line 905 of file mtc_generator.h.

◆ ColorSymbolTablep()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

SymbolTable * faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ColorSymbolTablep ( void ) const

Get Pointer to ColorSymbolTable currently used by this MtcSystem.

Returns: Pointer to ColorSymbolTable

Definition at line 900 of file mtc_generator.h.

◆ Copy()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > * faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::Copy ( void ) const

virtual

Construct copy on heap.

Returns: New Generator

Reimplemented from faudes::TcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >.

Definition at line 842 of file mtc_generator.h.

◆ CStr()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

std::string faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::CStr ( Idx index ) const

Return pretty printable color name for index.

Primary meant for debugging messages.

Parameters

index

Returns: std::string Color name

Definition at line 1288 of file mtc_generator.h.

◆ DelColor() [1/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DelColor ( const std::string & rColorName )

Remove color by name from all states.

Parameters

rColorName Name of state color

Definition at line 1128 of file mtc_generator.h.

◆ DelColor() [2/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DelColor ( Idx colorIndex )

Remove color by index from all states.

Parameters

colorIndex Index of state color

Definition at line 1142 of file mtc_generator.h.

◆ DelColor() [3/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DelColor	(	Idx	stateIndex,
		const std::string &	rColorName
	)

Remove color by name from an existing state specified by index.

Define FAUDES_CHECKED for consistency checks.

Parameters

stateIndex	State index
rColorName	Name of the state color

Exceptions

Exception

Index not member of set (id 200)
Name not found in NameSet (id 202)

Definition at line 1073 of file mtc_generator.h.

◆ DelColor() [4/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DelColor	(	Idx	stateIndex,
		Idx	colorIndex
	)

Remove color by index form an existing state specified by index.

Define FAUDES_CHECKED for consistency checks.

Parameters

stateIndex	State index
colorIndex	Index of the state color

Exceptions

Exception

Index not member of set (id 200)
Color index not found in generator (id 205)

Definition at line 1103 of file mtc_generator.h.

◆ DelColorName()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DelColorName ( Idx colorIndex )

Finally deletes a color name and its index from the currently used symbol table.

doxygen group

Parameters

colorIndex Index of color to delete from symbol table

Definition at line 1175 of file mtc_generator.h.

◆ DoAssign()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DoAssign ( const TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > & rSrc )

protected

Assignment.

Definition at line 853 of file mtc_generator.h.

◆ DoSWrite()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DoSWrite ( TokenWriter & rTw ) const

protectedvirtual

Token output, see Type::SWrite for public wrappers.

The method assumes that the type parameter is a faudes type and uses the provide write method per entry. Reimplement this function in derived classes for non-faudes type vectors.

Parameters

rTw	Reference to TokenWriter

Exceptions

Exception

IO errors (id 2)

Reimplemented from faudes::vGenerator.

Definition at line 1627 of file mtc_generator.h.

◆ DotWrite()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::DotWrite ( const std::string & rFileName ) const

virtual

Writes generator to dot input format.

doxygen group

The dot file format is specified by the graphiz package; see http://www.graphviz.org. The package includes the dot command line tool to generate a graphical representation of the generators graph. See also Generator::GraphWrite(). This functions sets the re-indexing to minimal indices.

Parameters

rFileName Name of file to save result

Reimplemented from faudes::vGenerator.

Definition at line 1309 of file mtc_generator.h.

◆ ExistsColor() [1/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ExistsColor ( const std::string & rColorName ) const

Check if color exists in generator.

Define FAUDES_CHECKED for consistency checks

Parameters

rColorName Color name which will be examined regarding existence in the generator

Returns: true if color exists

Exceptions

Exception

Color name not found in symbol table (id 202)

Definition at line 1265 of file mtc_generator.h.

◆ ExistsColor() [2/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ExistsColor ( Idx colorIndex ) const

Check if color exists in generator.

Parameters

colorIndex Index which will be examined regarding existence in the generator

Returns: true if color exists

Definition at line 1256 of file mtc_generator.h.

◆ ExistsColor() [3/3]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::ExistsColor	(	Idx	stateIndex,
		Idx	colorIndex
	)		const

Check if color exists in a given state of the MtcSystem.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex	Index which determines the generator's state
colorIndex	Color index to look for in given state

Returns: true if color exists in state

Exceptions

Exception

Index not member of set (id 200)

Definition at line 1293 of file mtc_generator.h.

◆ GlobalColorSymbolTablep()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

SymbolTable * faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::GlobalColorSymbolTablep ( void ) const

Get Pointer to global ColorSymbolTable.

doxygen group This is a static member of ColorSet and used as default for all derived classes and instantiated objects.

Returns: Pointer to global ColorSymbolTable

Definition at line 895 of file mtc_generator.h.

◆ InsColor() [1/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColor	(	Idx	stateIndex,
		const std::string &	rColorName
	)

Insert a color by name into an existing state.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex	Index of state to be set as colored state
rColorName	Name of state color to be added

Returns: Index of inserted color

Exceptions

Exception

Index not member of set (id 200)
Name already exists / invalid name (id 104)

Definition at line 986 of file mtc_generator.h.

◆ InsColor() [2/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColor	(	Idx	stateIndex,
		Idx	colorIndex
	)

Insert a color by index into an existing state.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex	Index of state to be set as colored state
colorIndex	Index of color to be added to state, must already exist in symbol table

Exceptions

Exception

State index not member of set (id 200)
Color index not known to symbol table (id 200)

Definition at line 1014 of file mtc_generator.h.

◆ InsColoredState() [1/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColoredState ( const ColorSet & rColors )

Create a new unnamed state and set the colors from rColors.

Parameters

rColors Color set

Returns: Index of new unique state

Definition at line 979 of file mtc_generator.h.

◆ InsColoredState() [2/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColoredState	(	const std::string &	rStateName,
		const ColorSet &	rColors
	)

Create a new named state and set the colors from rColors.

Parameters

rStateName	Name of the state to add
rColors	Color set

Returns: Index of new unique state

Definition at line 972 of file mtc_generator.h.

◆ InsColoredState() [3/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColoredState	(	const std::string &	rStateName,
		const std::string &	rColorName
	)

Create a new named state and set the color rColorName.

doxygen group

Define FAUDES_CHECKED for consistency checks

Parameters

rStateName	Name of the state to add
rColorName	Name of the state color

Returns: Index of new unique state

Exceptions

Exception

Name already exists (id 104)
Index not member of set (id 200)

Definition at line 915 of file mtc_generator.h.

◆ InsColoredState() [4/4]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

Idx faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColoredState	(	const std::string &	rStateName,
		Idx	colorIndex
	)

Create a new named state and set the color colorIndex.

Define FAUDES_CHECKED for consistency checks

Parameters

rStateName	Name of the state to add
colorIndex	Index of the state color, must already exist in symbol table

Returns: Index of new unique state

Exceptions

Exception

Color index not known to symbol table (id 200)

Definition at line 953 of file mtc_generator.h.

◆ InsColors()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::InsColors	(	Idx	stateIndex,
		const ColorSet &	rColors
	)

Insert multiple colors from a color set into an existing state.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex	Index of state to be set as colored state
rColors	Reference to color set with colors to set for state, colors must already exist in symbol table

Exceptions

Exception

State index not member of set (id 200)
Symbol table mismach (id 200)
Symbol table mismatch (id 88)

Definition at line 1040 of file mtc_generator.h.

◆ IsColored() [1/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::IsColored ( Idx stateIndex ) const

Check if the given state is colored or not.

Define FAUDES_CHECKED for consistency checks

Parameters

stateIndex State to examine

Returns: True if given state is colored

Exceptions

Exception

State index not member of set (id 200)

Definition at line 1498 of file mtc_generator.h.

◆ IsColored() [2/2]

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::IsColored ( void ) const

Check if there is at least one colored state in the MtcSystem.

Returns: True if there is at least one colored state

Definition at line 1489 of file mtc_generator.h.

◆ IsStronglyCoaccessible()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::IsStronglyCoaccessible ( void ) const

Check if MtcSystem is strongly coaccessible.

Returns: True if generator is strongly coaccessible

Definition at line 1542 of file mtc_generator.h.

◆ IsStronglyTrim()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::IsStronglyTrim ( void ) const

Check if the MtcSystem is strongly trim.

Returns: True if generator is strongly trim

Definition at line 1568 of file mtc_generator.h.

◆ New()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > * faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::New ( void ) const

virtual

Construct on heap.

Returns: New Generator

Reimplemented from faudes::TcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >.

Definition at line 828 of file mtc_generator.h.

◆ NewColorSymbolTable()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

void faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::NewColorSymbolTable

Insert a new local color symbol table.

doxygen group mpColorSymbolTable is reset. The color symbol table pointer in every state attribute's mColors is also reset to the new symbol table. If there already exist color entries in the current symbol table, they are copied to the new local one.

Define FAUDES_CHECKED for consistency checks

Exceptions

Exception

Could not insert index and symbol to symbol table (id 44)

Definition at line 1580 of file mtc_generator.h.

◆ operator=()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

virtual TmtcGenerator& faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::operator= ( const TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr > & rOtherGen )

inlinevirtual

Assignment operator (uses Assign)

Note: you must reimplement this operator in derived classes in order to handle internal pointers correctly

Parameters

rOtherGen Other generator

Definition at line 139 of file mtc_generator.h.

◆ StateColorMap()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

std::map< Idx, ColorSet > faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::StateColorMap ( void ) const

Return a color map with state indices and their corresponding colors.

Only states with asociated colors are part of this list.

Returns: color map Standard library map where states and corresponding colors are saved

Definition at line 1441 of file mtc_generator.h.

◆ StronglyCoaccessible()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::StronglyCoaccessible ( void )

Make generator strongly coaccessible.

Forbidden states are deleted.

Returns: True if generator is strongly coaccessible

Example: Computation of the strongly coaccessible form of an MtcSystem

Original MtcSystem gen

From state 3 states with other colored markings cannot be reached. So, this generator is weakly coaccessible w.r.t. its color set, but not strongly coaccessible w.r.t. it.

Result of gen.StronglyCoaccessible();

Resulting MtcSystem is strongly coaccessible w.r.t its new color set where the color of the primary state 3 is missing

Definition at line 1535 of file mtc_generator.h.

◆ StronglyCoaccessibleSet()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::StronglyCoaccessibleSet ( void ) const

Generate a state set with all strongly coaccessible states.

doxygen group

Returns: StateSet Coaccessible states

Definition at line 1513 of file mtc_generator.h.

◆ StronglyTrim()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

bool faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::StronglyTrim ( void )

Make generator strongly trim.

Therefore, the forbidden states are deleted.

Returns: True if generator is strongly trim

Example: Computation of the strongly trim form of an MtcSystem

Original MtcSystem gen

State 5 is not accessible and from state 3 other states with other colored markings cannot be reached. So, this generator is not accessible and weakly coaccessible w.r.t. its color set.

Result of gen.StronglyTrim();

Resulting MtcSystem is strongly trim, which means accessible and strongly coaccessible w.r.t its color set

Definition at line 1554 of file mtc_generator.h.

◆ StronglyTrimSet()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::StronglyTrimSet ( void ) const

Generate a state set with all the strongly trim generator's states.

Returns: StateSet All states for which generator is strongly trim

Definition at line 1547 of file mtc_generator.h.

◆ UncoloredStates()

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

StateSet faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::UncoloredStates

Returns a state set containing all states that are not colored.

Returns: State set containing uncolored states

Definition at line 1479 of file mtc_generator.h.

Member Data Documentation

◆ mpColorSymbolTable

template<class GlobalAttr , class StateAttr , class EventAttr , class TransAttr >

SymbolTable* faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >::mpColorSymbolTable

protected

Pointer to currently used symbol table.

Definition at line 721 of file mtc_generator.h.

The documentation for this class was generated from the following file:

mtc_generator.h

Detailed Description

template<class GlobalAttr, class StateAttr, class EventAttr, class TransAttr> class faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Constructor & Destructor Documentation

◆ TmtcGenerator() [1/4]

◆ TmtcGenerator() [2/4]

◆ TmtcGenerator() [3/4]

◆ TmtcGenerator() [4/4]

◆ ~TmtcGenerator()

Member Function Documentation

◆ Assign()

◆ CheckSymbolTable() [1/2]

◆ CheckSymbolTable() [2/2]

◆ ClearStateAttributes()

◆ ClrColors()

◆ ColoredStates() [1/3]

◆ ColoredStates() [2/3]

◆ ColoredStates() [3/3]

◆ ColorIndex()

◆ ColorName()

◆ Colors() [1/3]

◆ Colors() [2/3]

◆ Colors() [3/3]

◆ ColorSymbolTable() [1/2]

◆ ColorSymbolTable() [2/2]

◆ ColorSymbolTablep()

◆ Copy()

◆ CStr()

◆ DelColor() [1/4]

◆ DelColor() [2/4]

◆ DelColor() [3/4]

◆ DelColor() [4/4]

◆ DelColorName()

◆ DoAssign()

◆ DoSWrite()

◆ DotWrite()

◆ ExistsColor() [1/3]

◆ ExistsColor() [2/3]

◆ ExistsColor() [3/3]

◆ GlobalColorSymbolTablep()

◆ InsColor() [1/2]

◆ InsColor() [2/2]

◆ InsColoredState() [1/4]

◆ InsColoredState() [2/4]

◆ InsColoredState() [3/4]

◆ InsColoredState() [4/4]

◆ InsColors()

◆ IsColored() [1/2]

◆ IsColored() [2/2]

◆ IsStronglyCoaccessible()

◆ IsStronglyTrim()

◆ New()

◆ NewColorSymbolTable()

◆ operator=()

◆ StateColorMap()

◆ StronglyCoaccessible()

Example: Computation of the strongly coaccessible form of an MtcSystem

◆ StronglyCoaccessibleSet()

◆ StronglyTrim()

Example: Computation of the strongly trim form of an MtcSystem

◆ StronglyTrimSet()

◆ UncoloredStates()

Member Data Documentation

◆ mpColorSymbolTable

template<class GlobalAttr, class StateAttr, class EventAttr, class TransAttr>
class faudes::TmtcGenerator< GlobalAttr, StateAttr, EventAttr, TransAttr >
